JY-500HA-R

Technical Data

Cutting capacity(mm)

500*500

Blade speed(m/min)

20-80 INVERTER SPEED

Blade size(mm)

41*1.3*5640

Main Motor(kw)

5.5

Hydraulic Motor(kw)

1.5

Cooling motor power(w)

90

Work-piece Clamping

Hydraulic Vise

Blade Tension

Manual

Material feed

Manual

Machine size(mm)

2950*2200*1925

Machine weight(kg)

2780

Standard Equipment

Blade cleaning brush

Power blade cleaning brush

Working light

YES

One piece of bi-metal saw blade

YES

One set of tools with tool box

YES

Operation manual

YES

Out-feed with auxiliary plate table

YES

Manual work height control

YES

package

Steel and plywood

Unit price FOB NINGBO(USD):

Option parts

1.Roller table :

2.Band saw blade

3.Hydraulic blade tension

4.Auto chip conveyor
